代号 | 类型 | 大外径D1 | 小外径D2 | 内径D3 | D4 | D5 | D6 | 小内径D7 | D8 | N | 总高H1 | 小外径高H2 | H3 | H4 | H5 | H6 | H7 | h | A1 | D01 | D02 | D03 | D04 | D05 | D06 | D07 | D08 |
SD466 | FZ2 | 55 | 50 | 5 | 33 | 27 | 43 | 2.5 | 6 | 13 | 3.5 | 8 | 6 | 0.03 | 30 | ||||||||||||
SD342 | FZ1 | 35 | 30.8 | 16 | 21 | 19 | 28 | 15 | 7.3 | 4.3 | 4 | 30 | |||||||||||||||
SD566 | FZ1 | 27.5 | 23.8 | 18 | 19 | 22 | 20 | 9.5 | 4.5 | 2.2 | 2 | ||||||||||||||||
SD461-1 | FZ2 | 27.4 | 25 | 6 | 20.8 | 18 | 25.4 | 1 | 3 | 11.5 | 4 | 4.4 | 1.8 | 0.2 | 26 | 9.1 | 16 | 17.9 | 9.7 | 14.5 | 17.9 | 21 | 23 | ||||
SD463 | FZ2 | 32.7 | 30 | 6 | 27 | 21 | 28.5 | 2 | 6 | 12.5 | 3.5 | 5.4 | 2.5 | 0.4 | 20 | 9.5 | 18 | 20.5 | 11 | 18.5 | 20.5 | 25.5 | 28 | ||||
SD036-1 | FZ2 | 35 | 32 | 5 | 25.6 | 21 | 28 | 2 | 6 | 11 | 3 | 6.2 | 4.8 | 0.03 | 30 | 8.5 | 18.2 | 19.4 | 18.8 | 20 | 26.5 | 27.7 | |||||
SD600 | FZ2 | 33 | 30 | 5 | 24.5 | 20.2 | 26 | 2 | 4 | 11.8 | 3.3 | 5 | 4 | 0.05 | SR38.5 | 9 | 18 | 19.2 | 9 | 17 | 18.2 | 26 | 27.2 | ||||
SD628 | FZ2 | 28 | 28 | 5 | 20 | 17 | 22 | 1.5 | 2 | 11.8 | 3.3 | 5 | 4 | 0.05 | SR38.5 | 8.5 | 14.5 | 16.5 | 8.5 | 14.5 | 16.5 | 20.7 | 22.2 | ||||
SD084-1 | FZ2 | 38 | 35 | 5 | 24 | 20 | 26 | 2 | 3 | 12.2 | 3.5 | 7 | 5.2 | 30 | 7.5 | 15.3 | 16.5 | 15.7 | 16.9 | 24.4 | 25.6 | ||||||
SD083-13 | FZ2 | 33 | 30 | 5 | 22 | 18 | 23.6 | 2.1 | 3 | 11 | 3 | 7 | 4 | 0.08 | SR38.5 | 7.5 | 15.3 | 16.5 | 15.2 | 16.3 | 22.4 | 23.6 | |||||
SD098-2 | FZ2 | 28 | 25 | 6 | 20.5 | 18 | 24.5 | 1.8 | 3 | 11 | 3.8 | 5.5 | 3 | 0.03 | 30 | 8.5 | 15.7 | 17 | 15.7 | 17 | 21.4 | 22.6 | |||||
SD028-3 | FZ2 | 33 | 30 | 5 | 22 | 18 | 28 | 2 | 6 | 11.8 | 3 | 7.3 | 4.5 | 0.03 | 30 | 7 | 15.3 | 16.3 | 15.4 | 16.4 | 22.8 | 23.8 |
